300rpm Peristaltic Reagent Dosing Pump for Mineral Processing

Product Introduction

The G300-1F peristaltic dosing pump is designed for controlled liquid transfer and reagent dosing applications. With a speed range of 0.01–300 rpm and 0.01 rpm speed resolution, it provides flexible adjustment for different dosing requirements.

The pump features a 4.3-inch industrial color LCD, flow calibration, multiple operating modes, external control and RS485 communication. It can be integrated into mineral processing reagent dosing systems as a liquid metering and delivery component.

Key Features

• 0.01–300 rpm Speed Range – Fine adjustment with 0.01 rpm speed resolution.
• Flow Calibration – Allows flow parameters to be calibrated according to actual operating conditions.
• Multiple Operating Modes – Flow, Filling, Timed Quantitative and Fixed-Speed Quantitative modes.
• External Control – Supports 0–5V, 0–10V, 4–20mA and 0–10kHz signals.
• RS485 / Modbus – Suitable for integration with compatible process control systems.
• Multiple Pump Heads – Compatible with YZ1515, YZ2515, DG Series, DMD15, YT15 and YT25.
• IP65 Protection – Designed for industrial operating environments.

Technical Specifications

Mineral Processing Reagent Dosing

The G300-1F can be integrated into mineral processing reagent dosing systems for controlled liquid delivery.

Reagent Tank → Peristaltic Dosing Pump → Dosing Pipeline → Process Dosing Point

Pump head and tubing should be selected according to the required flow range and chemical compatibility of the liquid.

FAQ

Q: Can the pump be integrated into an automatic dosing system?
Yes. It supports external control and RS485 communication for integration with compatible control systems.

Q: Can it be used for flotation reagent dosing?
It can be used as a liquid metering and delivery component for suitable reagents. Tubing and pump-head compatibility should be confirmed according to the specific liquid.
